The Unexpected Reason Why F1 Cars Have a Wooden Plank
Key Takeaways
- The skid block, a wooden panel, helps to control the F1 car’s ride height and has a safety function of controlling downforce and bottoming out.
- It's interesting to know that the plank was introduced to the Formula 1 races after the tragic accident at the 1994 San Marino Grand Prix.
- Although the plank looks very simple, it impacts the design of the car, race strategy, and performance.
- The plank is actually made from a composite material called Jabroc (dense beechwood laminate) or resin-based materials like Permaglass, despite commonly being referred to as a simple wooden plank.
- Teams face disqualification if post-race technical scrutiny reveals that the plank has worn down beyond the maximum allowed threshold (1 millimetre).
If you are a follower of Formula 1 racing, then you must have noticed that there is a wooden plank fixed at the bottom of every car. The plank has two main uses. First is the regulation of minimum ride height.
By assessing the wear of the plank over the course of a race, the minimum ride height of the car is regulated. The second one is for safety. It regulates the speed of the car by restricting the amount of downforce that acts on it. Safety is the prime motive behind both these usages since it restricts the speed of the car and its downforce.
Reason for Introduction of Wooden Planks
The implementation of the skid block came after the sad deaths of Roland Ratzenberger and Ayrton Senna in the 1994 San Marino Grand Prix. Ratzenberger’s crash happened due to the front wing of his car getting stuck below the car in a crash that took place at 195.7 mph.
Ayrton’s crash happened due to the malfunctioning of the steering column, which caused a crash that led to his death. The FIA, in reaction, implemented the skid block to forcibly raise the height of the cars and reduce downforce, especially on high-downforce turns.
Protective Function of the Plank
Role of the Skid Block:
- Prevention of Bottoming Out: It helps avoid bottoming out so as to prevent the sudden loss of downforce that results in porpoising in F1 cars.
- Reduction in Downforce: The increased ride height reduces the downforce exerted on the vehicle.
1. Porpoising
The phenomenon of porpoising occurs when the car is bottoming out, resulting in a bouncing effect owing to an interruption in the airflow under the car. The plank helps to prevent this problem because it raises the height of the car and reduces downforce, but it does not stop porpoising from happening. Recent modifications, like the rule by the FIA to raise floor edges, have been made to solve this problem.
2. Less Downforce
Downforce helps improve traction and speed; however, when downforce is too high, the vehicle will be lowered more than it should be, causing the problem called porpoising. With the plank, the car will have its ride height raised, which reduces downforce.
You May Also Like: F1 Out Laps, In Laps and Hot Laps Explained Right Here
Impact of Plank on F1 Teams
The rule of having a minimum ride height of the plank has brought considerable changes to the design of the car. The designers had to alter the design to make sure that there is no damage to the plank since damage that is severe may result in disqualification. All cars in F1 have been slowed down but are now safer than before. The plank should be:
- Uniform Thickness: 10 mm ± 0.2 mm
- Hole Positions: Four specific holes for thickness measurement
- Material: Any homogeneous material meeting specific requirements
- Construction: Made from at most three pieces, with the forward piece at least 900 mm long
- Skids: Metallic skids can be added in place of plank material, visible from below, and made from titanium alloy
Plank Material Used in F1
Initially made from Jabroc, a composite wood, the plank is now made from Permaglass, a glass-reinforced laminate that is strong, durable, light, and non-flammable. This material ensures smooth degradation, posing no risk to drivers or spectators.
Plank Wear and Disqualification Issues
The FIA permits a wear margin of 1 mm on the plank. When this wears out, the car becomes disqualified, since excessive wear means the car is too low and generates a lot of downforce and thus runs the risk of porpoising.
The punishment for excessive wear on the wooden plank could be quite harsh since this is considered an infringement of the rules governing the build and operations of Formula One cars. Teams have been fined, lost championship points, or worse, been disqualified from racing due to non-compliance with the rules governing the wooden plank.
In order to mitigate wear on the wooden plank, teams have introduced titanium plates in order to slow the wear and keep the car low to generate maximum downforce. The plank must be firm according to FIA rules; however, engineers have found loopholes to make flexible planks in order to reduce car heights for increased performance.
Evolution and Future of the Wooden Plank on F1 Cars
The evolution of the wooden plank design and construction has been necessary to keep up with the changing times in F1 racing. Teams strive to develop a car that will enable them to win in races, and hence the wooden plank has also undergone some changes. The wooden plank is now made from a specific type of wood that makes it both strong and light.
As the sport evolves in the future, it is likely that the development of the wooden plank used in racing will change too. This is due to the advances in technology that will enable teams to increase the efficiency of the race cars. Although the wooden plank looks like an insignificant part of the racing car, its significance cannot be overlooked.
Similar Reads You May Enjoy: F1 Flags Meanings: What Different Colors Mean in F1 Racing
Conclusion
At first sight, the use of wooden planks on F1 cars looks rather unusual; however, their function in controlling the ride height and adhering to safety requirements is essential for the efficient functioning of such fast racing vehicles. With time, further developments in technology are expected to lead to changes in the design and construction of the wooden plank to meet the new demands of F1 racing.
The wooden plank is one of the most important elements of safety in F1 because it helps keep the ride height of cars within the safe parameters and limits the amount of downforce to avoid any accidents.
FAQs
1. Why does a wooden plank exist under the F1 car?
The wooden plank aids in balancing the car's ride height and avoids teams running their cars at low levels to achieve more downforce. Moreover, it increases the safety of the F1 race because of less bottoming out of the cars.
2. Does the F1 plank consist of real wood?
Though referred to as a wooden plank, modern F1 skid blocks are fabricated using advanced composite materials such as Permaglass, which is both light and tough enough.
3. What will happen if a plank on an F1 car wears out too much?
A car could be disqualified if the plank is worn past the permitted limit by the FIA. Wearing out means the car was running low, which would give it an unfair advantage.
4. How does the plank in the F1 car provide safety for the driver?
The plank is used to prevent the cars from coming very close to the ground due to dangers associated with excessive downforce, bottoming out, and lack of control due to unstable airflow.
5. When was the F1 wooden plank used first?
The FIA introduced the skid plate after the unfortunate 1994 San Marino Grand Prix, where the deaths of Roland Ratzenberger and Ayrton Senna brought about significant changes to Formula 1 from the standpoint of safety.
